Sports application
The supplied material positions this series for sports-field and stadium perimeter use.
LK-SA · SPORTS PERIMETER LED
LK-SA Stadium Perimeter LED Display
Built around the field edge.
LK-SA is an outdoor sports-field LED display system. The supplied series information shows P5, P6.667, P8 and P10 options, a 960 × 960 mm cabinet format, soft-mask modules and an adjustable holder for perimeter-screen applications.
- Pixel-pitch range
- P5–P10
- Cabinet format
- 960 × 960 mm
- Perimeter hardware
- Soft mask + adjustable holder
NEXSHOWSSPORTS PERIMETER LED DISPLAY
WHY THIS SERIES
A perimeter display system shaped around the field edge.
LK-SA adds sports-specific physical features to an outdoor LED cabinet platform. Soft-mask modules, an adjustable rear holder and the P5 to P10 pitch range support perimeter layouts where viewing angle, impact protection and cabinet stability all matter.
The final perimeter layout should be checked against field geometry, sightlines, screen angle, access routes and event safety requirements before the cabinet count is confirmed.
Soft-mask module
A soft-mask module is shown to help protect the display face around the field edge.
Adjustable support
The cabinet visual includes an adjustable holder for the physical screen arrangement.
Outdoor pitch options
P5 to P10 options are shown for outdoor sports viewing distances.
PERIMETER HARDWARE
Protect the display face and control the cabinet angle.
The supplied system shows a soft-mask module at the front and an adjustable holder at the rear. Together they make the cabinet suitable for the physical arrangement of a sports perimeter screen.
- Soft-mask LED module
- Adjustable rear support
- 960 × 960 mm cabinet format
VENUE PLANNING
Design for spectators, cameras and the playing area.
Pitch and cabinet angle should follow the expected viewing distance and broadcast sightline. NexShows uses the venue drawing to plan the perimeter length, cabinet quantity and service route.
- Stadium and sports-field use
- P5, P6.667, P8 and P10 options
- Project-specific angle and quantity planning
PROJECT FIT
Where LK-SA Series belongs.
The final perimeter layout should be checked against field geometry, sightlines, screen angle, access routes and event safety requirements before the cabinet count is confirmed.
- Sports fields
- Stadium perimeters
- Event venues
- Outdoor sports media
SERIES SPECIFICATIONS
Key system data.
AVAILABLE CONFIGURATIONS
Compare the supplied models.
| Pixel pitch | Brightness shown | Service | Cabinet |
|---|---|---|---|
| P5 | ≥5500 cd/m² | Rear or front | 960 × 960 mm |
| P6.667 / P8 | ≥6000 cd/m² | Rear or front | 960 × 960 mm |
| P10 | ≥6000 cd/m² | Rear or front | 960 × 960 mm |
The figures shown are taken from the supplied LK-SA series material. NexShows confirms the final system layout, protection approach and screen configuration with each project.
